OTC Teach Pendant Cable L21501B00 for FD11 Controller

OTC Teach Pendant Cable L21501B00 for FD11 Controller

OTC Teach Pendant Cable L21501B00 is a teaching operating handle cable specially designed for FD11 controller. Made of high-quality materials to ensure its durability and stability. Its precisely designed connector ensures reliable connection with the teaching operating handle and controller, effectively avoiding communication interruptions or signal instability. Easy to install and easy to operate, even those unfamiliar with electrical connections can quickly complete the connection. The stability and reliability of the cable make it an indispensable part of the industrial robot system, providing operators with convenient operation and ensuring the normal operation of the robot system. Whether in industrial production lines or other automation applications, this cable can play an important role in ensuring efficient communication between the teaching operating handle and the controller, thereby improving production efficiency and work quality.

Technical Specifications

Application Scenarios

The L21501B00 cable serves critical functions in various industrial automation scenarios:

1. Robotic Welding Systems

In arc welding applications using OTC FD11-controlled robots, the cable enables real-time parameter adjustments during pulse welding processes with current ranges of 50-350A. Operators can modify welding paths while maintaining ±0.1mm repeatability.

2. Automotive Assembly Lines

For spot welding operations in automotive production, the cable supports programming of up to 999 weld points per program with 0.01mm positioning accuracy. Its EMI shielding prevents interference from nearby 15kVA welding transformers.

3. Material Handling Systems

When integrated with FD11-controlled palletizing robots, the cable facilitates programming of 600+ cycles/hour with payloads up to 150kg (330 lbs). The robust construction withstands continuous flexing in 24/7 operation environments.

4. Machine Tending Applications

For CNC machine loading/unloading, the cable enables precise positioning within ±0.05mm tolerance while operating near cutting fluids and metal chips. The IP54-rated connectors prevent contamination ingress.

Installation and Maintenance

Installation Guidelines

• Route cables away from high-voltage power lines (minimum 30cm/12in separation)

• Use strain relief clamps at 50cm (20in) intervals for overhead installations

• Ensure proper connector alignment before mating (0.5mm maximum misalignment)

• Verify pin continuity with 4-wire ohmmeter (resolution 0.1Ω)

Preventive Maintenance

Troubleshooting

Common issues and diagnostic procedures:

• Intermittent Communication: Check for shield continuity and measure common mode noise (<2V p-p)

• Pin Damage: Inspect with 10x magnification for bent or corroded pins

• Cable Flex Fatigue: Measure conductor resistance (<0.5Ω per 3m length)

Environmental Considerations

The L21501B00 cable is designed for harsh industrial environments:

• Resistant to IRM 903 oil and 5% NaCl spray (500hr salt fog test)

• Withstands UV exposure for 1,000 hours without jacket degradation

• Flame rating meets UL 94 V-0 standards for vertical flame test

• Flex life of 500,000 cycles at 90° bend angle (IEC 60227-6 test)

FAQ：

What is OTC Teach Pendant Cable L21501B00 for FD11 Controller?

OTC Teach Pendant Cable L21501B00 is a teaching operating handle cable specially designed for the FD11 controller. It is used to connect the teaching operating handle and the controller so that the operator can control the industrial robot system. It is a cable with a specific interface that plays the role of connecting and transmitting data.

What are the main functions of OTC Teach Pendant Cable L21501B00 for FD11 Controller?

The main function is to ensure a stable connection between the teaching operating handle and the FD11 controller to ensure the operator's effective control and operation of the industrial robot system. It realizes the operation and monitoring of the robot by transmitting instructions and data, transmitting the operator's instructions to the controller, and transmitting the controller's feedback back to the operating handle.

What is the connection interface of OTC Teach Pendant Cable L21501B00 for FD11 Controller?

This cable has a precise connector design and is suitable for the interface between the teaching operating handle and the FD11 controller. Usually plug-in connections are used to ensure stable connection and communication quality.

What is the material of OTC Teach Pendant Cable L21501B00 for FD11 Controller?

Made of high-quality materials, such as a stretch-resistant, wear-resistant plastic outer sheath and a conductive metal core, the cable has good durability and stability and can operate reliably for a long time in industrial environments.

Can OTC Teach Pendant Cable L21501B00 for FD11 Controller improve the efficiency of industrial robot operations?

Yes, using this cable can increase the efficiency of industrial robot operations due to its stable connection and high-quality materials. It ensures that operators can control the robot system more smoothly and accurately, thereby improving operational efficiency and work quality.

How to install OTC Teach Pendant Cable L21501B00?

Installation is easy, just connect the cable to the interface of the teaching operating handle and FD11 controller, make sure the plug fully fits the interface, and ensure the connection is firm to complete the installation.

Is this cable compatible?

Yes, OTC Teach Pendant Cable L21501B00 is specially designed for the FD11 controller. It has good compatibility with it and can fit perfectly. At the same time, it also has the possibility of being compatible with other models of teaching operating handles and controllers.

Can using OTC Teach Pendant Cable L21501B00 reduce enterprise maintenance costs?

Yes, due to its high quality and stability, using OTC Teach Pendant Cable L21501B00 can reduce repair and replacement costs due to cable failures. This helps companies save maintenance costs and improve production efficiency.
